05Sinus & Complex Cases
“The posterior maxilla stops most GPs. Not you.”
Overview
The posterior maxilla stops most general practitioners — thin bone, close sinus floor, complex anatomy. Module 5 removes that barrier completely. You will learn both crestal (osteotome) and lateral window sinus lift techniques, then apply one on a real patient. Full-arch rehabilitation concepts (All-on-4, All-on-6) are also introduced so you can begin planning full-mouth reconstructions.
Learning Outcome
“Confident managing posterior maxilla — the anatomical zone that stops most general practitioners.”
Every dental practice has patients who need posterior maxillary implants. After this phase, you treat them — you don't refer them.
What You Will Be Able To Do
- Assess maxillary sinus anatomy, Underwood septa, patency of the ostiomeatal complex, and sinus pathology on CBCT
- Perform crestal osteotome sinus floor elevation (Summers technique) for 3–5mm vertical bone gains
- Execute lateral window antrostomy step-by-step using rotary and piezoelectric ultrasonic tips
- Manage Schneiderian membrane perforations systematically using resorbable collagen membranes and PRF
- Plan All-on-4 and All-on-6 full-arch surgical cases with tilted posterior implants and multi-unit abutments

Day-by-Day Schedule
Day 21
Maxillary Sinus Anatomy & Sinus Pathology Assessment
Day 22
Crestal (Osteotome) Sinus Lift — Technique, Instruments & Cases
Day 23
Lateral Window Sinus Lift — Step-by-Step & Membrane Management
Day 24
Full Arch Planning — All-on-4/6 Concepts & Bar-Retained Overdentures
Day 25
LIVE PATIENT: Sinus Lift or Complex Multi-Unit Case
Clinical Focus Areas
In-Depth Technical Competencies
Crestal vs Lateral Window Decision Matrix
Residual bone height (RBH) ≥5mm with favorable crestal width allows crestal osteotome elevation with simultaneous implant placement. RBH <4–5mm requires a lateral window approach to safely elevate the Schneiderian membrane and pack adequate graft volume.
Schneiderian Membrane Preservation & Perforation Rescue
Techniques for peeling the antral mucoperiosteum without laceration. Step-by-step repair protocols for Class I/II tears (<5mm) with cross-linked collagen barriers, tissue sealants, and conversion protocols.
Full-Arch Biomechanics (All-on-4/6)
Tilting posterior implants up to 30–45° avoids maxillary sinus invasion while maximizing anterior-posterior spread, eliminating long cantilever arms and providing cross-arch rigidity for immediate loading.
Surgical & Diagnostic Kit
Clinical Armamentarium Used
Every resident personally handles full hospital-grade instrumentation during this module, moving beyond observation into tactile mastery:
- Summers sinus osteotomes (concave, convex, graduated with depth stops)
- Lateral window sinus lift kit: round diamond burs, sinus curettes with anatomical angles
- Piezoelectric surgical unit with specialized sinus membrane detachment tips
- Sinus graft condensers, syringes, and slow-resorbing bone matrix
- Multi-unit abutments (straight, 17°, 30° angulations) and torque drivers
Only 10 Seats.
Is yours one of them?
Live Surgery from Day 1. NABH-accredited facility. Real patients, not mannequins.
Global Dental Education · Visakhapatnam, India
